Specifications: |
|
|
|
Manufacturing
Standards |
|
Meets applicable safety and EMC
certification standards; UL and CE certified |
|
Communication
Interface |
|
RS-232
or GSIOC; Two TTL-compatible inputs for control of start/stop and
direction of flow and one analog input (0–5V) for variable control
of motor speed |
|
Environmental
Conditions |
|
Indoor use
Altitude: up to 2000 m
Temperature range: 5–40°C
Air pressure: 75–105 kPa
Pollution degree: 1 or 2, in accordance with IEC 66
Humidity: Maximum relative humidity 80% for temperatures up to
31°C, decreasing linearly to 50% relative humidity at 40°C |
|
Flow Rate |
|
Standard
flow rates (1, 2, 4, or 8 channels): 0.3 µL/min–30 mL/min at a
maximum pressure of 0.5 MPa.
High flow rates (2 or 4 channels): 1 mL/min–220 mL/min at a
maximum pressure of 0.3 MPa |
|
Head Speed |
|
Continuous adjustment from 0 to 48 rpm
by 0.01 rpm increments up to 9.99 rpm and by 0.1 rpm increments
above 10 rpm |
|
Motor Speed
Stability |
|
0.5% for
any variation of line voltage, torque, or temperature |
|
Peristaltic Tubing
Diameter |
|
Standard model: 0.25–4 mm (ID)
High-Flow model: 2–8 mm (ID) |
|
Power Requirements |
|
Frequency: 47–63 Hz
Voltage: 90–132 or 180–264V; mains voltage fluctuations not to
exceed ±10% of the nominal voltage
Consumption: Full load 45W at 220V; no load 35W at 220V |
|
Pump Heads |
|
Standard model: 1-, 2-, 4-, or
8-channel heads with 10 stainless steel rollers per head
High-Flow model: 2- or 4-channel heads with five stainless steel
rollers per head |
|
Software |
|
Via UniPoint™ System Software or Trilution™ Software |
|
Dimensions (w x d x
h) |
|
15 x 17.5 x 18 cm (5.9 x 6.9 x 7.1
in.) |
|
Weight |
|
4 kg (9
lbs.) |
